Rotolavit II-S
The Hettich Rotolavit II-S automates the washing of your flow cytometry samples
- Takes care of the wash steps in the sample preparation
- Centrifuges, decanters and resuspends cells automatically
- Rotors are compatible with the PS-10 pipetting station
The Hettich Rotolavit II-S automates the washing of your flow cytometry samples. The technician places the rotor, selects the correct washing program and can continue with other activities. The PS-10 integration makes it easy to transfer the rotors to and from the pipetting station. This together makes the cell washer a real step forward for routine lab work.
Configure your own washing program
The Hettich Rotolavit II-S can store up to 20 programs. The programs can be configured by arranging the process steps in any desired order. Your technician can change the settings of the process steps in terms of centrifuge time, speed and PBS volume. With these flexible properties, the Rotolavit II-S is ideal for carrying out your washing protocols.
User-programmable steps |
|
Dispense volumes | 0.1 ml to 4 ml per sample tube |
Accuracy | Sample fill volume ± 15% |
Speed | Up to 3500 rpm |
Force | Up to 1438 RFC |
Kinetic energy, max. | 250 Nm |
Suitable rotors | 12 position swing out rotor, 24 position swing out rotor |
Sample Tube capacity | Up to 12 or 24 tubes (depending on rotor used) |
Compatible sample tubes |
|
Dimensions H x W x D | 280 mm x 330 mm x 480 mm (closed lid) Height with open lid: 580 mm |
Weight | approx. 24.4 kg |
Power requirements | 100 to 240 V / 50/60 Hz / 150 W / 144 VA / Fuse: 10 A / 250 V F |
